atvise® hmi
Easily visualize complex things.
Freedom has a name - atvise®
atvise® hmi is a fully functional web HMI as a standard product. With many available process interfaces, a convenient engineering tool and unlimited freedom in user interface design, we help shorten development cycles and reduce costs.
All benefits at a glance
The benefits of atvise® hmi
Through the use of proven and widely used technologies
Easy cascadability and online engineering
Through consistent object orientation and engineering by drag & drop
Fully customizable object catalog and support for modern front-end frameworks such as React, Angular and Vue
Fast results
With the atvise® builder as engineering tool with full graphic support, atvise® hmi offers everything needed for the rapid implementation of HMIs. In addition to an extensive object catalog, drag & drop support and consistent object orientation, atvise® hmi users also have a fully integrated responsive-design framework at their disposal.
Ready for any machine
With an integrated OPC UA client and atvise® connect as a communication driver for Siemens and Rockwell controllers as well as for Modbus, KNX, MQTT and BACNet, nothing stands in the way to easily gather data in your HMI application.
Scalable architectures
Due to the integrated onboard OPC UA server, atvise® hmi applications can be easily expanded at any time. For example, after successful implementation of the HMI, a higher-level atvise® scada application can be implemented afterwards without interrupting the operation of the HMI applications.
Open for any front end
In the implementation of HMIs, atvise® hmi offers a great deal of design freedom for implementation. The following options are available for implementation:
- Pure drag-&-drop engineering based on SVG
- Modification of our standard components and expansion of the object catalog with HTML-based controls
- 100 % customized front end based on modern frameworks such as React, Angular or Vue
atvise® product features
| Feature | atvise® embedded | atvise® hmi | atvise® scada | atvise® bundles |
| Web technology Native web technology with HTML5, CSS3 and JavaScript for visualization | ||||
| Engineering Graphically supported online multi-user engineering with a diverse object catalog and consistent object orientation | ||||
| Security State of the art with integrated management of certificates and encryption via SSL | ||||
| Vertical Engineering Consistent object orientation in the engineering of data structures |
| |||
| OPC UA server & client Onboard OPC UA server and client with support for OPC UA DA, A&C, HA, Methods |
| |||
| Access Control Fine grained control of permissions based on OPC UA Rights | ||||
| Communication drivers Integration of Siemens and Rockwell controllers as well as Modbus TCP, KNX, BACNet, SNMP and MQTT devices |
| |||
| Connection of databases Interaction with databases via ODBC |
| |||
| Integration of web services Interaction with web services via http |
| |||
| Integrated alarming Alarm management with support for functions such as shelving, suppression and deactivation |
| |||
| Integrated archiving Archiving of raw data with variously parameterizable ring buffers |
| |||
| Aggregation Compression of raw data with more than 40 available aggregation functions, which can be nested as desired |
| |||
| Reporting Automatic generation of individual PDF-Reports | ||||
| Server-side scripting Integrated server-side scripting engine for process data processing |
| |||
| SCADA alarm technology Dynamic enrichment and prevention of alarms with nestable alarm hierarchies |
|
| ||
| Hot-standby redundancy Implementation of redundant atvise® applications for critical applications |
|
|
Technologies
What atvise® hmi builds on
atvise® expansions
These expansions make atvise® hmi even better
Would you like to scale that up a little?
These solutions are optimally suited for use in large projects
atvise® information material
The most important information about our products at a glance
