atvise® embedded
Right in the center and not on the sidelines.
Piece by piece towards a masterpiece
atvise® embedded is our modular software toolkit implemented in ANSI-C with the ability to extract the visualization part of atvise® and integrate into other software and hardware solutions. The benefits? Software applications with atvise® embedded benefit from an open web interface that can be used out of the box for a fully functional web HMI. All that's left to do is to define the source of the data to be displayed. Sounds good, doesn't it?
All benefits at a glance
The benefits of atvise® embedded
Through the use of a proven solution
Web technology turns any terminal with a web browser into a client
Through prepared graphic objects and engineering via drag & drop for the end user
Together we create an attractive pricing scheme based on the market requirements of the finished solution
Web server as a basis
The basis of atvise® embedded is a lean web server. It has all the necessary interfaces to access process data, alarms and historical data. The atvise® embedded guidelines we provide make it possible to quickly and easily define sources for the interfaces to display data. Once the interfaces have been defined, the atvise® embedded server will be ready and the engineering of native HMI applications can start.
Extensive modular system
With a wide range of prepared graphic objects, many available dynamizations and responsive-design support, atvise® embedded offers everything needed for the timely and efficient implementation of a web HMI. Once created, a project can be quickly and easily transferred to the atvise® embedded server via our engineering tool. This can happen during operation, without the need to restart the runtime at all. You can read about what else our engineering tool has in store here.
atvise® product features
| Feature | atvise® embedded | atvise® hmi | atvise® scada | atvise® bundles |
| Web technology Native web technology with HTML5, CSS3 and JavaScript for visualization | ||||
| Engineering Graphically supported online multi-user engineering with a diverse object catalog and consistent object orientation | ||||
| Security State of the art with integrated management of certificates and encryption via SSL | ||||
| Vertical Engineering Consistent object orientation in the engineering of data structures |
| |||
| OPC UA server & client Onboard OPC UA server and client with support for OPC UA DA, A&C, HA, Methods |
| |||
| Access Control Fine grained control of permissions based on OPC UA Rights | ||||
| Communication drivers Integration of Siemens and Rockwell controllers as well as Modbus TCP, KNX, BACNet, SNMP and MQTT devices |
| |||
| Connection of databases Interaction with databases via ODBC |
| |||
| Integration of web services Interaction with web services via http |
| |||
| Integrated alarming Alarm management with support for functions such as shelving, suppression and deactivation |
| |||
| Integrated archiving Archiving of raw data with variously parameterizable ring buffers |
| |||
| Aggregation Compression of raw data with more than 40 available aggregation functions, which can be nested as desired |
| |||
| Reporting Automatic generation of individual PDF-Reports | ||||
| Server-side scripting Integrated server-side scripting engine for process data processing |
| |||
| SCADA alarm technology Dynamic enrichment and prevention of alarms with nestable alarm hierarchies |
|
| ||
| Hot-standby redundancy Implementation of redundant atvise® applications for critical applications |
|
|
Expansions + technologies
What atvise® builds on
The same technology as standard software?
No problem, all of atvise® embedded's technological benefits are also available in the form of comprehensive standard products!
